3KW High Temperature Cartridge Heater For Plastic Injection Molding Machines

Changshu Flex-Tek Thermal Fluid Systems Manufacturer Co., Ltd.

3KW High Temperature Cartridge Heater For Plastic Injection Molding Machines

Brand Name : Tutco

Model Number : 110V 100W

Certification : UL

Place of Origin : China

MOQ : 1

Packaging Details : Standard Exporting Packing

Price : negotiation

Shell : SS304 & Incoloy

Temperature : High temperature & High density

Filling Material : MI & Mgo

Voltage : 220V

Wattage : 3KW

Brand : TUTCO

Contact Now

Professional Customizing Mold Heating Element Cartridge Heater

Description of Mold Heating Element Cartridge Heater:

Mold Heating Element Cartridge Heaters are used largely used to heat liquid, solid or gas, the application in plastic industry is very wide, such as hot runner system,smallmould heating ,plastic package ,Medical equipment plastic ,plastic injection molding machine nozzle heating, Package and cartridge is also used in the cigarette industry, footwear industry, thermoforming machinery.
High-wattage cartridges belong to a new generation of electric heating elements; they make it possible to use high watt loads in small spaces, thus ensuring excellent reliability in heavy-duty work conditions. Their special construction technology makes them the most advanced type of heating elements. The entire length of the wire wound around a magnesium oxide core is in a faraway position from the axis of the cartridge, very close to the metal sheath, with a very thin and compressed insulating wall in between; this allows excellent heat exchange that allows a much lower temperature of the resistance wire than in other heaters in which the wire is in a deeper position. Besides the use of advanced technology and precise inspection techniques in their manufacturing, Ultramar cartridge heater owe their total reliability to the use of first-class material from the best sources in the market.

Datasheet of Mold Heating Element Cartridge Heater:

  • Single-Ended tubular heater covering: SUS304/SUS316L/Incoloy 800/Titanium etc.
  • Insulation: Compacted magnesium Oxide
  • Heating conductor: NiCr8020
  • Voltage: 6V to 415v
  • Power density: Maxi 50W/CM2
  • Temperature resistance: 800 centi degree
  • Size tolerance: Less than 0.6mm
  • Thermocouple: J type, K type etc.

Typical Application:

  • Plastic Injection Molding Machines
  • Plastic Extruders
  • Oil Reclamation Equipment
  • Food and Candy Extruders
  • Drum Heating
  • Extrusion Dies
  • Holding Tanks
  • Blow Molding Machines
  • Vending Machines
  • Food Service Warming
  • Autoclaves & Sterilizers
  • Metallurgical Analyzers
  • Fluidized Beds

3KW High Temperature Cartridge Heater For Plastic Injection Molding Machines

3KW High Temperature Cartridge Heater For Plastic Injection Molding Machines

Why TUTCO
1. Heater is UL listed for Outdoor Applications
2. All of the limit controls in all TUTCO duct heaters are automatic resets or are manually resettable. There are no devices that have to be replaced when tripped.
3. In a horizontal airflow application, the airflow direction is not specific; it can go either direction without any modification.
4. With our wire rack element suspension system, the heater coil is less susceptible to airflow shading and allows a very small pressure drop across the coils.
5. All TUTCO duct heaters carry a zero clearance rating for installations into ducts.
